Product Series：1300 Wall Panel Type Shaftless Turret Unwinder And Rewinder

1300 Wall Panel Type Shaftless Turret Unwinder And Rewinder

Technical parameters:
Maximum unwinder and rewinder diameter:Φ1300mm;
Minimum splicing diameter for unwinder: Φ400mm;
Up and bottom paper splicing;
3" or 6" pneumatic expansion chuck or mechanical expansion chuck;
Dancing roller tension control;
Internal pressure roller for rewinder;
Width: 1450, 1750mm, other widths can be customized;
Velocity: 250~650m/min;
Optional: active splicing roller equipped with a drive mechanism; can help prevent scratches;
Gear disk rotation speed: 1RPM.
